composer require topthink/think-worker
composer require topthink/think-worker
config
目录下生成三个文件 gateway_worker.php
worker.php
worker_server.php
2.配置
<?php
// +----------------------------------------------------------------------
// | ThinkPHP [ WE CAN DO IT JUST THINK IT ]
// +----------------------------------------------------------------------
// | Copyright (c) 2006-2018 http://thinkphp.cn All rights reserved.
// +----------------------------------------------------------------------
// | Licensed ( http://www.apache.org/licenses/LICENSE-2.0 )
// +----------------------------------------------------------------------
// | Author: liu21st <liu21st@gmail.com>
// +----------------------------------------------------------------------
// +----------------------------------------------------------------------
// | Workerman设置 仅对 php think worker:gateway 指令有效
// +----------------------------------------------------------------------
return [
// 扩展自身需要的配置
'protocol' => 'websocket', // 协议 支持 tcp udp unix http websocket text
'host' => env('gateway.host','127.0.0.1'), // 监听地址
'port' => env('gateway.port',2348), // 监听端口
'socket' => '', // 完整监听地址
'context' => [], // socket 上下文选项
'register_deploy' => true, // 是否需要部署register
'businessWorker_deploy' => true, // 是否需要部署businessWorker
'gateway_deploy' => true, // 是否需要部署gateway
// Register配置
'registerAddress' => env('gateway.register_address','127.0.0.1:1238'),
// Gateway配置
'name' => 'ZsrdCrmGateway',
'count' => 1,
'lanIp' => env('gateway.lan_ip','127.0.0.1'),
'startPort' => 2000,
'daemonize' => false,
'pingInterval' => 10,
'pingNotResponseLimit' => 0,
'pingData' => '{"type":"ping"}',
// BusinsessWorker配置
'businessWorker' => [
'name' => 'BusinessWorker',
'count' => 1,
'eventHandler' => '\common\workerman\GatewayEvents',
],
];
<?php
/*
* +----------------------------------------------------------------------
* | wangqy
* +----------------------------------------------------------------------
* | Copyright (c) 2023 http://upwqy.com All rights reserved.
* +----------------------------------------------------------------------
* | Author: wangqy <529857614@qq.com>
* +----------------------------------------------------------------------
*/
namespace common\workerman;
use common\utils\Json;
use GatewayWorker\Lib\Gateway;
use think\worker\Events;
use Workerman\Worker;
class GatewayEvents extends Events
{
/**
* onConnect 事件回调
* 当客户端连接上gateway进程时(TCP三次握手完毕时)触发.
*
* @param int $client_id
*/
public static function onConnect($client_id)
{
$response = [
'type' => 'connect',
'client_id' => $client_id,
];
Gateway::sendToCurrentClient(json_encode($response));
}
/**
* onWebSocketConnect 事件回调
* 当客户端连接上gateway完成websocket握手时触发.
*
* @param int $client_id 断开连接的客户端client_id
* @param mixed $data
*/
public static function onWebSocketConnect($client_id, $data)
{
$response = [
'type' => 'web_socket_connect',
'client_id' => $client_id,
'data' => $data,
];
Gateway::sendToCurrentClient(json_encode($response));
}
/**
* onMessage 事件回调
* 当客户端发来数据(Gateway进程收到数据)后触发.
*
* @param int $client_id
* @param mixed $data
*/
public static function onMessage($client_id, $data)
{
$response = [
'type' => 'message',
'client_id' => $client_id,
'data' => Json::decode($data),
];
Gateway::sendToCurrentClient(json_encode($response));
}
/**
* onClose 事件回调 当用户断开连接时触发的方法.
*
* @param int $client_id 断开连接的客户端client_id
*/
public static function onClose($client_id)
{
$data = [
'type' => 'close',
'client_id' => $client_id,
];
GateWay::sendToClient($client_id, json_encode($data));
}
/**
* onWorkerStop 事件回调
* 当businessWorker进程退出时触发。每个进程生命周期内都只会触发一次。
*/
public static function onWorkerStop(Worker $businessWorker)
{
echo "WorkerStop\n";
}
}
'businessWorker' => [
'name' => 'BusinessWorker',
'count' => 1,
'eventHandler' => '\common\workerman\GatewayEvents',
],
php think worker:gateway
import { bindClient } from '@/api/user'
class Socket {
constructor() {
this.url = 'ws://127.0.0.1:2348'
this.webSocket = new WebSocket(this.url)
this.init()
}
init() {
// 监听是否连接成功
this.webSocket.onopen = () => {
// 连接成功则发送一个数据
this.send({ msg: '连接成功' })
}
// 接听服务器发回的信息并处理展示
this.webSocket.onmessage = (e) => {
const data = JSON.parse(e.data)
const type = data.type || ''
this.data = data
console.log(data)
switch (type) {
case 'connect':
this.bindUid()
break
}
}
// 监听连接关闭事件
this.webSocket.onclose = () => {
// 监听整个过程中websocket的状态
console.log('连接已关闭')
}
// 监听并处理error事件
this.webSocket.onerror = function(error) {
console.log(error)
}
}
bindUid() {
bindClient({ client_id: this.data.client_id }).then(res => {
console.log('bind_client success')
})
}
send(obj) {
this.webSocket.send(JSON.stringify(obj))
}
}
export default Socket
然后在需要使用的地方 new Socket()
即可。
<?php
/*
* +----------------------------------------------------------------------
* | wangqy
* +----------------------------------------------------------------------
* | Copyright (c) 2023 http://upwqy.com All rights reserved.
* +----------------------------------------------------------------------
* | Author: wangqy <529857614@qq.com>
* +----------------------------------------------------------------------
*/
namespace common\workerman;
use common\utils\Json;
use GatewayWorker\Lib\Gateway;
class GatewayPush
{
public function __construct()
{
Gateway::$registerAddress = '127.0.0.1:1238';
}
public static function bindUid($clientId, $uid)
{
Gateway::bindUid($clientId, $uid);
}
public static function sendToClient($clientId, $type = 'message',array $data = [])
{
$response = [
'type' => $type,
'client_id' => $clientId,
'data' => $data,
];
return Gateway::sendToClient($clientId, Json::encode($response));
}
}
前提条件及准备工作:
1、已经安装nginx,版本不低于1.3
2、假设Workerman监听的是8282端口(websocket协议)
3、已经申请了证书(pem/crt文件及key文件)假设放在了/etc/nginx/conf.d/ssl下
4、打算利用nginx开启443端口对外提供wss代理服务(端口可以根据需要修改)
5、nginx一般作为网站服务器运行着其它服务,为了不影响原来的站点使用,这里使用地址 域名/wss
作为wss的代理入口。也就是客户端连接地址为 wss://域名/wss
上面是官网给出的流程,我这里根据实际情况调整为如下几步。也可以去Workerman官网去查看关于WSS相关的文章
第一步:在网站设置中开启SSL,证书可以自创建或者使用阿里云的免费证书
第二步:在配置中加入如下代码
location /wss
{
proxy_pass http://127.0.0.1:2348;
proxy_http_version 1.1;
proxy_set_header Upgrade $http_upgrade;
proxy_set_header Connection "Upgrade";
proxy_set_header X-Real-IP $remote_addr;
}
第三步:将ws连接更改为 wss://域名/wss
通过上面三步配置后,执行命令:php think worker:gateway
刷新后台网站,可以看到连接成功。
另外目前所使用的服务器是单服务器,所以服务器上的配置和本地测试的时候是一样的
.env 配置如下:
[GATEWAY]
HOST = 127.0.0.1
PORT = 2348
LAN_IP = 127.0.0.1
REGISTER_ADDRESS = 127.0.0.1:1238
